TIMBER GLAZED PARTITIONS



High acoustic performance up to Rw 54dB.

60 minute fire rating

REQUEST CONSULTATION
TIMBER GLAZED PARTITIONS



High acoustic performance up to Rw 54dB.

60 minute fire rating

REQUEST CONSULTATION

Imola is a fully certified and third party tested partitioning system. Imola incorporates single and double glazed, solid / veneered panel and door modules. Glazed elevations are available with mullion and or transom style design or glass-to-glass dry joint for continuous glass wall effect.

Imola masters the challenge of achieving aesthetic design combined with outstanding performance; acoustics (up to Rw 54dB) and fire rating up to EI 60 (integrity  / insulation) and structural performance (Severe Duty).

The standard design door modules offer the choice of traditional positioned doorstop, flush rebated door & frame and the Imola unique concealed door frame with sequentially matched veneer panel and door. A number of transition posts cater for differing wall starts and drywall conditions including stylish shadow gap features.

Imola products are manufactured in an environmentally responsible manner, the company has been assessed by Control Union Certification for FSC® (Forest Stewardship Council ®) and PEFC (Programme for the Endorsement of Forest Certification schemes) Chain of Custody.

Tested and certified by IFC Group, specialist fire safety consultancy.

ACOUSTIC PERFORMANCE

• Glazed Screens up to Rw 54dB
• Timber Doors up to Rw 43dB

FIRE RATING

• Double and Single Glazed option to EI30 (integrity and Insulation).
• Double and Single Glazed option to EI60 (integrity and Insulation).

FEATURES

• Integrated and fully concealed electronic locking
• Offset hinges on floor springs
• Timber and glass doors available
• Framed or frameless glazing is available

“Companies with healthy and happy employees are two times more innovative.”
— GENSLER U.S. WORKPLACE SURVEY 2016
“People exposed to nature show a boost in their performance on creative problem-solving by 50%.”
— BUSINESS INSIDER
“75% of employers ranked stress as their top health + productivity concern.”
— WILLIS TOWERS WATSON
“A happy and healthy workplace is the foundation for a successful business.”
— ARTHUR GENSLER

Case Studies

UCD TIERNEY BUILDING

Centralised Administration Building

Double glazed Imola timber partitions with an acoustic rating of Rw 51dB and 60 minute single glazed fire rated screens / doors.

ALDI HEADQUARTERS

Food Testing Facility

Double glazed  Imola timber glazed partitions achieving an exceptional acoustic rating of Rw 53dB. Switch glass was utilised allowing for the utmost privacy.

HSE JERVIS STREET

Health Administration Building

Imola timber paneling combined with Imola timber glazed partitioning brings a natural warmth to this workspace.

UCD TIERNEY BUILDING

Centralised Administration Building

Double glazed Imola timber partitions with an acoustic rating of Rw 51dB and 60 minute fire rated screens / doors

ALDI HEADQUARTERS

Food Testing Facility

Double glazed  Imola timber glazed partitions achieving an exceptional acoustic rating of Rw 53dB. Switch glass was utilised allowing for the utmost privacy.

HSE JERVIS STREET

Health Administration Building

Imola timber paneling combined with Imola timber glazed partitioning brings a natural warmth to this workspace.

READ THE LATEST NEWS
Celebrating 25 years of Allied!

Celebrating 25 years of Allied!

25 years of growing our company, innovating with our product ranges and expanding our team. We’re proud to have worked on so many prestigious projects over the past...

read more

SYSTEM DETAILS

Glass to Glass

Glazed Mullion or Glass to Glass
(Dry Joint Gasket or optional silicon)

1. Single Centre Glazing
2. Single Offset Glazing
3. Double Glazing

Doors

1. Standard door and frame
2. Flush face door and frame
3. Concealed doorframe with
sequentially matched veneer
panel and door.
4. Full Height Standard Door set.



Solid Matching Panels

1. Wrap round transition
2. Flush shadow gap
3. Tech panel
(prepared for room
book system)

Headtrack Detail

Double Glazed Faceted

Single Glazed Offset

Mullion free glass to glass dry joint

Door Frame

Seamless integration between door frame and glazing.

WOOD • WORKPLACE • WELLBEING



In a global Study conducted by the World Green Building Council, natural elements, particularly wood and light had impacts on happiness, creativity and productivity. Workers in the UK reported 15% increase in well-being and are 6% more productive with a reduction in abstention rates.

There is a growing awareness of the importance of connecting buildings with the natural world. With biophilic design and using natural elements like wood we can bring nature indoors and provide a healthier, happier environment for all (1)

Research has long shown that exposure to the natural environment positively impacts human health and well-being, both physical and psychological. Lower blood pressure and reduced levels of aggression are just some of the measured positive outcomes in humans. Increasingly, those same benefits are being attributed to wood visible in the built environment, such as timber systems and finishes. The link between wood and human health has been demonstrated clearly in studies in Japan, the US, Canada and are also emerging in Europe. A study conducted by the University of British Columbia refitted similar offices with different materials and measured health aspects of the occupants. It is found that as visual wood surfaces in a rooms increased, sympathetic nervous system activation was lowered, which is responsible for physiological stress responses.(2)

(1)(source https://makeitwood.org/healthandwellbeing/)

(2)Augistin, S and Fell, D., Wood as a restorative Material in Healthcare Environments, FPInnovations, University of British Columbia, 2014

Sample Imola Veneer Gallery
